Dimmer for Dioramo Lighting System including JST-XH Unplug Tool

Dimmer for Dioramo Lighting System including JST-XH Unplug Tool

$17.93 - $17.93
$17.93
$17.93 - $17.93
$17.93

Product Specifications for Dioramo Scale Modeling #20102 Dimmer

Dioramo Scale Modeling

#20102

Dimmer for the Dioramo Lighting System

10-Port Light Dimmer with Expansion and Switch Ports, Compatible with our Easy-Peasy Plug & Play Lighting System.

  • Buttery-Smooth Dimmer offering stable, full-range Light Dimming, all the way down to 0%.
  • This Dimmer works with any Dioramo Lighting System Compatible Light, Switch, Power Supply, and Cables.
  • Daisy-chain modules together using Expansion Cables to increase available Light Ports - up to 150 Lights!
  • The Dioramo Lighting System has a Fail-Safe design. You can't cause harm by accidentally connecting parts the wrong way. If the plug fits into a connector, then it may be connected there.
  • Includes Mounting Screws (#55330), and a JST-XH Connector Unplug Tool (#50101), to safely and easily disconnect Lights. An optional Die Cut 3M VHB Double-sided Adhesive Pad for screwless mounting is also available (#55201).



Perfect for Quick and Easy Lighting your Hobbies, Diorama Scenery, Model Train Layouts, DIY Projects, Crafts, Architectural Displays, Toys, Diecast Cars, RC, Dollhouses, Miniature Light Fixtures, Plastic Kits, Legos, Toy Minis, Costumes, 3D Prints, Christmas Village, Holiday Decorations, and more!



Notes:

  1. The Dimmer dims all the Lights plugged into the Light Ports, together.
  2. The Switch Port turns ON-OFF all the Lights plugged into the Light Ports; it does not affect the Expansion Port. The Expansion Port passes power through to other connected (daisy-chained) modules.
  3. An unlimited number of modules (Hubs, Dimmers, Blinkers, etc.) may be connected to / daisy-chained from the Dimmer's Expansion Port, as long as the Maximum Device Current Rating (150 Lights / 3000mA) through any connected module is not exceeded.
  4. The "Product Specifications" and "Lighting System Catalog" PDFs offer additional system and technical information.

Embracing Modularity

  • The Dioramo Lighting System is Never Obsolete.
  • Only get the parts you want, to build exactly what you need.
  • Grow your Lighting System as your project expands.



Specifications:

Dimensions:
(incl. Mounting Wings & Knob)		 3.79 in. × 1.6 in. × 0.95 in.
96.35 mm x 40.5 mm x 24.0 mm
Operating Voltage: 5-15 V (volts)
Maximum Device Current: 3000 mA (milliampere), or
150 Dioramo Lighting System Compatible Lights
Power Port: DC Barrell Connector. Size: 5.5mm x 2.1mm
(Anode (+) on the inside pin)
Light Ports: JST XH-A2 Connectors
(Anodes (+) on Pin 1)
Switch Port: JST XH-A3 Connector
(See Product Specifications PDF for technical info)



This Dimmer is included in the following Set:

Dioramo Lighting System - PRO Set



All Types - Dioramo Lighting System Compatible Products





Important:

The Dioramo Lighting System is designed to be both an Easy-Peasy Plug-and-Play Solution and a Customizable System for DIY Builders. Our DIY Adapters and Cables allow for both approaches.

DIY Connections, however, are done at your own risk. Faulty DIY connections resulting in a short circuit may damage the module's electronics.
